Q-Box®
Perfect protection of the environment.
![REMBE® Q-Box®](/templates/re2023/cache/8c/Q_Box_305x610_Studio_2015_05_cmyk_mod_IF._h1000-8c4bcb6c.png)
![Made in Germany](/templates/re2023/cache/62/made-in-germany-small_version-62c7ca8a.png)
The Q-Box® is designed for plant components that are at risk of dust explosions, such as filters, elevators or silos with KSt-Values less than 200 bar × m/s and large explosion venting areas.
Application
The rectangular connection complements the dimensions of standard explosion vents, thus allowing it to be retrofitted to existing indoor and outdoor equipment. The sanitary cover protects the Q-Box® against dust from outside sources. Q-Box® is also suitable for outdoor application. Easy retrofitting: The dimensions of the Q-Box® perfectly match the dimensions of REMBE® standard explosion vents.
Advantages
- Flexible use of the Q-Box® permits process-efficient plant design.
- Reduces noise levels.
- Perfect protection of the surrounding area.
- Neither heat, dusts nor a dangerous pressure wave emerge from the vessel – everything stays in the Q-Box®.
- Cost-effective alternative to venting ducts. No running costs for venting ducts and external maintenance, a visual inspection is sufficient.
- Integrated signalling unit for reliable monitoring.
- Reduced downtime: Access to the protected system doesn't require a safety-related locking mechanism (LOTO).
- Flexible solution for indoor and outdoor use.
- Simple retrofitting to existing explosion vent installations.
Mechanism
The special stainless steel mesh filter inlet developed by REMBE® cools the hot flame gases extremely efficiently (up to 1.500 °C (2.732 °F). This reduces the volume of gas ejected and extinguishes the explosion.
Technical data
Product parameters
KSt-Value | ≤ 200 bar × m/s |
Pmax | ≤ 9 bar |
Minimum ignition energy | ≥ 3 mJ |
Minimum ignition temperature | ≥ 380 °C |
Static response pressure | 0,1 bar |
Max. red. explosion pressure Pred | ≤ 2,0 bar (305 x 310 mm), ≤ 0,7 bar (586 x 920 mm) |
Ambient temperature | -40 to +60 °C |
Process temperature | -30 bis +180 °C (higher temperatures available on request) |
Dimensions and weight
Dimension | Height | Weight |
---|---|---|
305 x 610 mm | 500 mm | ca. 28 kg |
586 x 920 mm | 780 mm | ca. 77 kg |
Other measurements available on request.
Applications + Industries
- animal feed productions
- aspiration plants
- brewery
- conveyors
- destoners
- elevators
- filters
- food
- food production
- mills and grinding plants
- mixers
- recycling
- screens
- silo
- spray dryers
- wood processing
Certifications
![Meets the requirements of NFPA 68](/templates/re2023/cache/da/200px-NFPA_logo-da4e55d1.png)
Meets the
requirements of NFPA 68
Certified in
accordance with
EN 16009
EN 14797
EN 14797
SIL-equivalent
SIL 2
![ATEX EC type examination certificate no. GEX 19 ATEX 1001X](/templates/re2023/cache/04/200px-EX-logo-042a4cec.png)
ATEX EC type
examination
certificate no.
GEX 19 ATEX 1001X
recommended software
The combination of the Q-Box® and isolation systems prevents pressure waves and flames propagating to other parts of the plant.
![REMBE® Q-Box®](/templates/re2023/cache/06/2204_1_img_0942_mod_print_h1500-06c66745.jpeg)
![REMBE® Q-Box®](/templates/re2023/cache/4c/Q_Box_Dieffenbacher_h1500-4caa3260.jpeg)
![REMBE® Q-Box®](/templates/re2023/cache/2e/qbox-anwendung_h1500-2e487d9d.jpeg)
![REMBE® Q-Box®](/templates/re2023/cache/21/DSC02046_h1500-210e36ee.jpeg)
![REMBE® Q-Box®](/templates/re2023/cache/e6/DSC02058_h1500-e61346a0.jpeg)
Click and drag image to view.
![Q Box AR Viewer Ru](/images/produkte/explosionsschutz/flammenlose-druckentlastung/q-box/video/Q-Box-AR-viewer-ru.png)
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
