EXKOP^® Express

controller for all isolation devices.

In the case of an explosion, the EXKOP^® controllers receive a trigger signal (e.g. from the signalling unit of the Q-Rohr^®, an explosion vent, from a pressure sensor or IR-Flame detecor) and activate the connected isolation systems which prevents an explosion from propagating.

Advantages

One controller for all isolation systems (Quench valves QV II and QV III, Q-Bic™ as well as slide valves RSV and REDEX^® Slide).
Self-monitoring safety electronics with operating data storage up to 100.000 events.
REMBE^® iQ Safety Cockpit fähig.
System status and clear messages reported immediately via the touch panel (optional).
Online remote access possible (optional).

line extension

FMX-R 13

IR Flame Detector

The IR Flame Detector is an infrared sensor that is used for immediate detection of explosion flames and thus, together with the EXKOP^® Express control system, for explosion isolation of systems in order to prevent the propagation of an explosion to other parts of the plant.

Technical data

Product parameters

Supply voltage	110 V AC/60 Hz – 230 V AC/50 Hz**
Max. no. of connectable detectors (lines)	2 to 36 (x3)
Isolation systems	QV II, QV III, Q-Bic™, RSV, REDEX^® Slide
Max. no. of connectable isolation units	Depends on the special application
Power consumption	Depends on the special size
Potential-free relay contacts	from 4 to 64
Wire cross-section (fine wire with ferrule)	0,5 – 0,75 mm²
Ambient temperature	0 – 50 °C
Protection type	IP 65
ATEX category	zone free
Housing material	Sheet steel housing with powder- coated front
Dimensions (W × H × D)	Depending on the number of detectors and decoupling systems
Weight	Depending on the number of detectors and decoupling systems
Remote access	-
Touch Panel	✓

Our specialists will be pleased to assist you in finding a solution that matches your specific operating conditions.
** Depends on the size of the controller.

Applications + Industries

animal feed productions
aspiration plants
brewery
chemical industry
conveyors
destoners
elevators
filters
food
food production
mills and grinding plants
mixers
pharmaceutical industry
recycling
screens
silo
spray dryers
wood processing

Certifications

ATEX EC type
examination certificate no.
FSA 04 ATEX 1537 X

ATEX EC type
examination certificate no.
FSA 15 ATEX 1659 X

ATEX EC type
examination certificate no.
GEX 19 ATEX 1003X

Certified in
accordance with

EN 15089

Downloads

The EXKOP^® system is ideal in combination with explosion vents or flameless explosion venting solutions.

Click and drag image to view.
- view in AR
Scan the QR code with your iOS camera* to see an AR preview of the product.
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
