Isolation with explosion safety valve.


VENTEX® – passive explosion decoupling with Swiss precision.

VENTEX® valves are often used when explosion-proof decoupling of pressurized containers is required or air supply openings have to be secured effectively against flame and pressure discharge. The decades-old proven design offers you an effective, passive explosion safety solution. These valves can be controlled with or without external energy and offer simple and reliable explosion safety due to their extremely low response pressure and ease of maintenance.
VENTEX® can be used in plants that process combustible dusts (incl. metal dusts), gases or hybrid mixtures. Common application areas include the pharmaceutical industry, chemical/petrochemical companies and research laboratories.
VENTEX mit Zubehör


  • Low response pressure.
  • Short mounting distance.
  • used for Dust- and/or Gasexplosion (Inkl. metaldust + hybrid mixtures).
  • passive closing principle.
  • bi-directional isolation.
When there is no flow of air, the closing device is in the open position. Air flows around the open closing device. The pressure wave pushes the closing device against a seal, locking the valve and effectively preventing the spread of flames and pressure.
Technical data
Product parameters
passive action: completely without control, sensors and external energy
DN 100 - DN 600
for low, medium or high pressure: minimal pressure drop in the pipe
Dust load
for low dust load, maximum 50g/m3
suitable for all common media: metallic dusts, hybrid mixtures, gases and organic dusts
Flow velocity
for low flow velocity, maximum 25m/s
Prozess temperature
for low, medium or high process temperatures
Mode of operation
available as single acting (ESI-E) or double acting (ESI-D), or as a check valve (ESI-C)
Installation position
vertical or horizontal installation
Applications + Industries
  • animal feed productions
  • aspiration plants
  • brewery
  • chemical industry
  • chemical- petrochemical
  • filters
  • food
  • food production
  • mills and grinding plants
  • mixers
  • pharmaceutical industry
  • recycling
  • wood processing


Certified in
accordance with

EN 15089
ATEX EC type examination certificate no. FSA 21 ATEX 1708 X

ATEX EC type
examination certificate
no. FSA 21 ATEX 1708 X

The decades proven design offers you an effective, passive explosion safety solution.

Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
Your contact person
I will be happy to advise you about the most suitable Protection systems for your plant. Individually, in detail and taking all relevant parameters into ­account.
