Feature | Characteristics | Variations |
---|---|---|
Holder compatibility | ✓ | G-HL, Flange, IG-HP, IG(-S), Threaded Holder,U-Holder |
Signalling available | ✓ | NIMU, SIGU, BT-S, FOS, SB-(S), SBK-S |
Pulsating, Cycling | ✓ | - |
Vacuum resistance | absolute | - |
Back pressure resistance | ✓ | - |
KRG (ASME) 2 | 2 | - |
KRL (ASME) 2 | 2 | - |
Torque independent burst pressure | ✓ | - |
Tolerance | % | ± 10 (±5, -0/+10, +0/-10 on request) | - |
Manufacturing design range | % | 0 | - |
Operating ratio | % | 80 | - |
Non-fragmenting design | ✓ | - |
Temperature range | °C | -80 to 600* | - |
Leakrate | mbar l s-1 | 10-4 to 10-5 | - |
Material | min. °C | max. °C |
---|---|---|
Inconel | -196 | 450* |
Hastelloy | -196 | 400 |
Monel | -10 | 425 |
Nickel | -10 | 600 |
Stainless steel | -80 | 320 |
Titanium | -10 | 300 |
Tantalum | -10 | 250 |
PTFE | -79 | 230 |
FEP | -10 | 200 |
Process medium | Suitability |
---|---|
Gas | Steam | ✓✓ |
Liquid with gas cushion | ✓✓ |
Two phase flow | ✓✓ |
Hygienic applications | ✓✓ |
