NIMU

for processes with high tightness ­requirements.

REMBE® NIMU signalling unit
Reliable. German. Safety.
NIMU is a reusable, non-invasive detection system. After an overpressure event, and the associated opening of the rupture disc, the outlet part of the rupture disc holder must be removed, the rupture disc replaced, and afterwards the system can be put back into operation. The days when the signalling cables also had to be routed again to the respective switching box are finally over.
Additionally: The process is absolutely leak-tight. The blind tapping in the holder replaces the tapping which is usually required. The absence of cable glands (required for the holder tappings for conventional signalling cables) means that the cable glands used cannot become porous, thus preventing an escape of the process media.
REMBE® NIMU signalling unit on a KUB® in a holder
Advantages
  • Totally leak tight process.
  • Cost-effective signalling device.
  • Full bore relief.
  • Easy function testing and maintenance.
  • Eliminates false alarms.
  • Reusable.
Technical data
Product parameters
Working principle
Signal Indicator, Intrinsically safe device
Signal output
Relays switching output (for connection to PLC)
Protection class
IP 67
Housing material
Stainless Steel 316L
Cable
Dual core copper cable, PTFE coated, Standard 2m, longer cable on request
Holder
With blind tapping (1/4") in outlet part, no special holder height required, standard inlet part
Temperature
-50 to +200 °C
Installation
Non-magnetic austenitic stainless steel holders
Applications
  • autoclaves
  • chemical industry
  • chemical reactors
  • condensers
  • cryogenic applications
  • cryostats + transport containers
  • desalination plants
  • distillation towers
  • flare stacks
  • food production
  • FPSO applications
  • gas compressor modules
  • gas turbines for power generation
  • gas-tight pressure vessels
  • geothermal energy
  • hazardous goods containers
  • heat exchangers
  • intermodal containers for corrosive / aggressive media
  • isolation of safety valves
  • LDPE (thermoplastic)
  • LNG
  • mixers
  • oil and gas separation and treatment
  • petrochemical plants
  • power plants
  • process vessels
  • reactors
  • refineries
  • reverse osmosis systems
  • separators
  • silo
  • spray dryers
  • sterile tanks / aseptic tanks
Industries
  • aerospace
  • brewery
  • chemical- petrochemical
  • food
  • hydrogen
  • oil and gas industry
  • pharmaceutical industry

Certifications

ATEX EC type examination certificate no. IBExU15ATEX1018
ATEX EC type examination certificate no. IBExU15ATEX1018
Downloads

With NIMU, your process is absolutely leak-tight.

Click and drag image to view.

Scan the QR code with your iOS camera* to see an AR preview of the product.
NIMU AR Viewer Ru
The dimensions shown may differ from those of the actual product.
* Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
Norbert Schlüter, Research and Development, at REMBE® for 18 Years
"Non-invasive signalling is the only reasonable solution for processes that require a high level of tightness. I can personally confirm that the NIMU is totally reliable. I was involved at each of the stages in development and testing."
