doubleholder

for the use of two bursting discs ­connected in series.

REMBE® doubleholder
Reliable. German. Safety.
The use of two rupture discs in combination allows the process to continue safely after one disc has been destroyed as the process is still secured by a second (closed) disc. For this reason, production processes that use toxic or corrosive media or have variable or high back pressures are often protected by two rupture discs installed in series. These can either be installed individually or more elegantly in a double disc assembly rupture disc holder. This also makes it possible to use different types of rupture disc in combination, e.g. a three-section rupture disc and a reverse acting rupture disc. Likewise, the two rupture discs can be designed to respond at different pressures. The space between the two discs is monitored to ensure that no back pressure builds up and any leakages due to corrosion of the primary rupture disc are identified immediately.
The response pressures of the two discs depend on the operating conditions. Double disc assemblies are installed as insert units between welding neck flanges to DIN or ANSI standards. The flow direction must be observed during installation.
REMBE® doubleholder with Accessoires

T-piece (optional)

e.g. for the pressure gauge connection

Excess flow valve
(optional)

Advantages
  • Increased protection for bursting discs connected in series in processes/plants subject to extreme conditions, such as e.g. B. highly corrosive, polluting or highly toxic media are exposed.
  • Supplied with pre-assembly screws to allow assembly with the bursting disc prior to installation in the pipeline.
  • User-friendly: there is no need for time-consuming pre-assembly, as is the case with comparable designs.
Applications
  • autoclaves
  • chemical industry
  • chemical reactors
  • distillation towers
  • flare stacks
  • FPSO applications
  • gas compressor modules
  • heat exchangers
  • LNG
  • mixers
  • oil and gas separation and treatment
  • petrochemical plants
  • power plants
  • process vessels
  • reactors
  • refineries
Industries
  • chemical- petrochemical
  • hydrogen
  • oil and gas industry

All double disc assembly mounting units have pre-assembly bolts facilitating assembly to the rupture disc prior to installation in the pipeline or flange connection.

  • Click and drag image to view.

  • Scan the QR code with your iOS camera* to see an AR preview of the product.
    Doppelhalter AR Viewer Ru
    The dimensions shown may differ from those of the actual product.
    * Requires iOS 13, iPadOS 13, ARCore 1.9 or higher.
